Description
Aluminium Rack Frames
BGL-M01A
Single Bay – Angled work surface with angled back
Internal height (without optional keyboard drawer): 770mm (17ru)
Internal height (With optional keyboard drawer): 688mm (15ru)
Internal width: 563mm
Internal depth: 600mm
Worksurface height (to lowest edge): 910mm
Overall Dimensions: 1100mm high * 600mm wide * 754mm deep
BGL-M01F
Single Bay – Flatwork surface with angled back
Internal height (without optional keyboard drawer): 770mm (17ru)
Internal height (With optional keyboard drawer): 688mm (15ru)
Internal width: 563mm
Internal depth: 600mm
Worksurface height (to lowest edge): 910mm
Overall Dimensions: 1100mm high * 600mm wide * 754mm deep
BGL-M01A-FB
Single Bay – Angled work surface with a flat back
Internal height (without optional keyboard drawer): 770mm (17ru)
Internal height (With optional keyboard drawer): 688mm (15ru)
Internal width: 563mm
Internal depth: 700mm
Worksurface height (to lowest edge): 910mm
Overall Dimensions: 1100mm high * 600mm wide * 754mm deep
BGL-M01F-FB
Single Bay – Flatwork surface with a flat back
Internal height (without optional keyboard drawer): 770mm (17ru)
Internal height (With optional keyboard drawer): 688mm (15ru)
Internal width: 563mm
Internal depth: 700mm
Worksurface height (to lowest edge): 910mm
Overall Dimensions: 1100mm high * 600mm wide * 754mm deep
BGL-M01A-FB-N
Single Bay – Angled work surface with flat back – Narrow depth
Internal height (without optional keyboard drawer): 770mm (17ru)
Internal height (With optional keyboard drawer): 688mm (15ru)
Internal width: 563mm
Internal depth: 580mm
Worksurface height (to lowest edge): 910mm
Overall Dimensions: 1100mm high * 600mm wide * 634mm deep
BGL-M01F-FB-N
Single Bay – Flatwork surface with flat back – Narrow depth
Internal height (without optional keyboard drawer): 770mm (17ru)
Internal height (With optional keyboard drawer): 688mm (15ru)
Internal width: 563mm
Internal depth: 580mm
Worksurface height (to lowest edge): 910mm
Overall Dimensions: 1100mm high * 600mm wide * 634mm deep
