 One 5.8 GHz true diversity receiver modules with 10 auto-scannable frequencies. One-touch Scan &
Sync (ACT) button for fast and easy channel setup.
 50W Class-D amplifier to power a 5″ full-range driver.
 Built-in high-efficiency active antennas prevent accidental antenna breakage and ensure improved
reception distance and stable signal quality.
 The mixed output of wired mic, wireless mic and USB.
 3.5 mm line input accepts external iPod, MP3/CD/DVD player or laptop.
 Built-in Bluetooth to connect mobile devices for music streaming.
 Built-in one-button fade-in alarm siren for warning.
 ID code setting to prevent the interference from the same operating channel and increase compatible
channels at the same venue.
 External AC switching power supply for fast battery charge. Built-in high capacity lithium battery
provides the amplifier complete operation without AC power.
 4-hour full charge for 10-hour stand-by time.
 A 4-level battery indicator for monitoring the battery level and charging state.

Transmitters & Microphones
ACT-58H Handheld Transmitter
ACT-58HC Rechargeable Handheld Transmitter
ACT-58T Bodypack Transmitter
ACT-58TC Rechargeable Bodypack Transmitter
MM-107 Supercardioid Dynamic Microphone

Accessories
MB-10 Lithium-ion Rechargeable Battery (14.8 V / 2.6 AH)
SC-10 Storage and Carry Bag
MS-30 Tripod Microphone Stand

Technical Specifications
Power Output Class D, 50 Watts (max.)
Loudspeaker 5 ” Full-Range
Receivers 1, ISM
Audio Inputs Mic In Ø 6.3 mm × 1, Line In Ø 3.5 mm × 1
Audio Output Line Out Ø 3.5 mm × 1
Audio Player USB Player & Recorder
Bluetooth Connectivity Yes
Alarm Siren Yes
Installation Shoulder Strap, Hand Carry, Flat Surface or Microphone Stand
Power Supply AC | 14.8V/ 2.6A Rechargeable Battery (MB-10)
Dimensions 135 × 144 × 240 mm (W × H × D)
Weight (battery included) Approx. 1.8 kg
