Description
Long lasting brightness, minimal maintenance, eco-friendly features
Whether your projector needs are for the office, the class room or the board room, advanced Panasonic technologies like Daylight View Premium ensure bright, clear projected images even in brightly-lit rooms, while wasteful power consumption is reduced.
Optional Wireless projection is provided for PCs, iPads and similar devices. Flexible installation, via the 2x zoom lens and horizontal/vertical lens shift, adapt to a wide range of room sizes and shapes. The Panasonic-FX400EA can also use existing mounting positions and cabling, making it ideal for replacement units as well as first-time installations.
Fewer replacement parts mean lower maintenance
The FX400’s long operating life is achieved with its reliable optical system and dust-resistant structure, providing an unprecedented 6,000 hour lamp replacement cycle and an eco-filter that will not need replacing for 12,000 hours. As an added environmental advantage, the filter can be washed and re-used.
Images with better clarity, colour and depth
Distribution data is extracted for ultra-high, high, medium and low-range frequencies, then Panasonic’s image correction circuit optimally enhances each area of the screen. The result is more natural, life-like images with high definition and clarity.
In brightly-lit rooms, the FX400 automatically corrects for ambient brightness with a luminance sensor, and adjusts to optimise sharpness and brightness according to the surroundings. In conjunction with the Detail Clarity Processor 3, the realism and vividness of projected images is enhanced for high contrast, making them easier to view at all light levels.
Eco-conscious performance
The FX400 automatically adjusts brightness to the light conditions, reduces lamp power when there is no signal input or when it is in AV Mute mode and uses a low stand-by power level of 0.4W. All you need to do is press the ECO button on the remote.
Product Specs
|
Display technology |
3LCD 0.8″ |
|---|---|
|
Resolution (physical) |
XGA 1024 x 768 pixels, from VGA (640 x 480) to UXGA (1600 x 1200) |
|
Brightness (norm./eco. mode) in ANSI-Lumen |
4000 |
|
Contrast ratio |
600:1 |
|
Weight in kg |
6,0 |
|
Dimensions (W x D x H) in mm |
430 x 323 x 125 |
|
Noise level (full/eco) |
33/29 dB |
|
Lens system |
2x zoom manual f=24.0 to 47.2 mm/F=1.7 to 2.6 |
|
Projection distance |
1.2 m to 18.1 m |
|
Image size (diagonal) |
0.83 m to 7.62 m |
|
Throw ratio (distance to image width) |
1.48 to 2.96:1 |
|
Offset |
hor. +/-27 % man., vert. +/- 50 % man. |
|
Keystone correction |
vert. +/-30° man. |
|
Functions |
digital keystone correction, ceiling mount, rear projection, digital zoom, mask, freeze, OSD, DaylightView5, control via RS232, IR or LAN with Internet Browser, automatic air filter with dust sensor, password protection |
|
Lamp |
250 W UHM |
|
Lamp life time (normal/economy mode) |
up to 5000 h |
|
Power supply |
100 to 240V AC/ 50/60 Hz |
|
Power consumption (on/stand-by) |
330/ |
|
Video compatibility |
PAL/SECAM/NTSC, 480i/p, 525i/p, 576i/p, 625i/p, 720p, 1080i/p bei 50/60Hz |
|
Horizontal frequency |
15 to 91 kHz |
|
Scanning rate |
50 to 85 Hz |
|
Bandwidth |
162 MHz |
|
Inputs |
DVI-I, RGB in (1×15 pin D-sub), Audio in (2xjack), Video (1xRCA), S-Video (1xMini-DIN 4polig), Audio in (2xRCA) |
|
WLAN Specification |
Optional with module IEEE 802.11 b/g/n |
|
Outputs |
Audio out controlable (1xjack) |
|
RS232 port |
9 pin D-sub |
|
LAN port |
RJ45 for remote control and image transfer |
|
Mouse port |
— |
|
Sound system |
1 x 5 Watt mono |
|
Standard accessories |
projector, power cable, remote control, batteries, CD ROM with software Wireless Manager 5.5, logo transfer software and control software, manuals |
|
Warranty |
36 months |
|
Lamp warranty |
3 years or 3000 hours at max. 5 h/day or 1000 h/year |
